TVP high-vacuum insulation changes the physics in panels
Play Video
Technology
TVP is the highest expert in the world for high-vacuum applied to panels. By suppressing thermal losses from convection, the mastery of high vacuum plays a crucial role in ensuring maximum energy transfer from the sun to usable heat.
TVP high-vacuum insulation technology creates a new class of super-performing products and in addition, improves the overall system efficiency. Thermal Vacuum Power Charged™ technology uniquely allows to consistently deliver a massive amount of solar thermal energy above 100°C, to tackle most of the industrial applications requiring either medium temperature heat from 80 to 200°C or low pressure steam up to 10 bar; this huge addressable market cannot be served by traditional solar thermal collectors
Product
Massive energy produced
HIGHEST SUN-TO-THERMAL EFFICIENCY
>65% thermal peak efficiency at 100°C and >50% at 180°C
The better the insulation, the lower the thermal losses, the higher the efficiency, the higher the thermal energy production at parity on collector gross area; up to 2 GWh/y/MW
The higher the energy production, the lower the footprint at parity on thermal peak power; about 2400 m2/MW
The higher the energy production, the higher the CO2 emission cuts at parity on footprint ; up to 480 ton/y/MW
Hail resistance according to ISO 9806
With no degradation of performance over 25-year product lifetime
ZERO MAINTENANCE
No cleaning needed; no mechanical moving parts
No special or hazardous waste disposal; positive panel end-of-life value from selling high-value metals as scrap
Certified internationally as the world's best performing solar thermal collector
Massive energy delivered
System
TVP engineered a modular layout of the solar plant for large scale deployments to maximize energy delivery to the end-clients. Long strings of panels exploit the patented heat absorber piping with parallel flow under vacuum to minimize overall system thermal losses.
Their minimum pressure drop minimizes HTF circulating pump size and related electricity consumption. TVP custom crimped connectors suppress any water leakage of the system. Triangular or multi-layer support structures are used to adapt to either rooftop or ground mounting. Pre-insulated piping are deployed either aboveground or underground, crimped or welded.
The PLC-based SCADA manages the plant to work automatically and unattended. Has remote monitoring feature. Runs a variable flow rate of the HTF in the solar field loop to maximize thermal energy production in respect to real-time gathered irradiance inputs.
Thermal storage tank solutions, heat exchangers and application machineries (steam drum, ISG, MVR, absorption chiller, MED, etc) are also supplied and integrated if requested. We are ISO 9001 and 14001 certified regarding our EPC practices and processes.
Producing in volume 7 days per week, 20 shifts out of 21 per week
Play Video
Manufacturing
TVP engineered its production line layout and related workflow to maximize automation, production throughput and yield. Layout modularity has been pursued to facilitate replication, thus production capacity scalability. The production line relies on full insourcing of key machining, 30 in total out of which 6 TVP proprietary (dedicated to vacuum-tight sealing, welding and brazing, high-vacuum conditioning and leak detection) and 15 co-developed by TVP.
TVP developed a proprietary SCADA to perform tracking of processed and assembled part numbers, product traceability, real-time monitoring and data gathering for each industrial process; it is integrated with a statistical process control system which allows to assess the performance of each process, production machinery and line operator as well as to guide predictive maintenance and troubleshooting. We are ISO 9001 certified regarding our manufacturing practices and processes
Consistency
Resilient Energy in All Conditions
TVP high-vacuum insulation technology stands out with consistent, efficient heat production, even in challenging environments. Unaffected by common issues like wind, snow, hot ambient temperature and dust, our solutions ensure reliable energy output where other systems struggle, with no need for panels cleaning.
TVP works at > 80˚C even when covered by snow
TVP works at >180˚C even when covered by dust
80°C - 180°C Applications
MT-Power Serves Commercial & Industrial
65°C – 180°C Applications
2022 Sun-Shot Award
2021 Best Product Award
2021 Energy Efficiency Award
2012 Innovative Enterprise Award
2012 Best Product in Solar Industry Award
2009 Nova Best Innovation Award
AWARDS
