Our Project
Agility
UAE
Ocean Rubber Factory (ORF)
240 m2 solar field; 0.15 MWth
Ras Al-Khaimah, UAE
165 to 185ᣞC
Cables manufacturing
152 MWhth/y (634 kWh/y/m2)
Process heat
19,750 l/y of diesel
EPC
52 ton/y of CO2
Challenge
A multinational manufacturer of rubber cables, Ocean Rubber Factory, committed to reduce Scope 1 GHG emissions in its factories as part of its corporate ESG goals. Solar thermal to delivers 180ᣞC heat every day without any panel cleaning. ORF production machineries use diathermic oil as heat transfer fluid (HTF), and the client requires to avoid any risk of contamination of the HTF on its loop.
Solution
TVP integrates the client loop with an oil-to-oil heat exchanger, circulating in the TVP loop the same diathermic oil used by the client to avoid any risk of contamination. TVP delivers the required 180ᣞC temperature consistently throughout the year, without any panel cleaning, with minimal thermal losses due to soiling effect from dust accumulation on panel glass front plate.
